ASP-EBJ100/100S

Automatic Elastic Ring Making Machine

  • Buy it now
Choose model

Choose Model

ModelASP-EBJ100/100S
Production CapacityDepends on the stitches. Total stitch: 33、Output: 5 sec/piece
Machine Dimensions(W)1230X(D)1030X(H)1530mm ( With table and thread stand )
Power VoltageSingle Phase AC200~240V 50/60Hz
Air Pressure0.5 Mpa
Air Consumption30L/min
Stitch Length

Folding Length

150∼990mm(waistband circumferences 300∼1980mm)

Lapping size0(folded)∼13mm

Applicable elastic Width6mm ∼ 20mm (EBJ100S) 20mm ∼ 50mm (EBJ100)
Needle TypeDPx5 #14
Sewing SpeedMax 2500 SPM
Machine HeadJUKI LK-1920

Precise jointing or overlapping for superior comfor

Easy to adjust the width of the bands by two knobs only

The machine will stop automatically once the elastic ribbon has a joint or is depleted during continuous cycle sewing

ADDITIONAL TECHNICAL MODULES

A. PID thermal control ironing system

B. Stacke
