OVERLOCK

BK

BACK LATCHING

To prevent seam looseness, turn over the thread and then insert into overlock seaming at the beginning of sewing.

  • KD207 Hand wheel: Standard equipment of 700K/BK machine, optional for BK device.
  • Including BK232 sewing bed .

Available Model: 737L-504M-7, 747L-514M-7, 747L-514H-7
Self-installation : Y

BKT

Simply Auto Back Latch

It is an ECA extending function, the sewing efficiency is extremely high. The needle plate is specially designed with a suction channel to quickly retract the thread after trimming. The thread length is approximately 3cm.

Available Model:747L-514M-3-24/ECA/BKT
Self-installation : N

CT

Flat Suction Thread Chain Cutter Device

Take thread into trimmer tube by suction motor or air compressor.
(Applicable for 4~6 thread machine)

Available Model: 767L
Self-installation : Y

CTE CTE-U

Flat Suction Auto Thread Chain Cutter Device (with Sensor-controlled Energy-saving Device )

Sensor checks the fabric edge. It saves the energy consuming of air compressor system and also
saves thread consuming.
1. Vertical suction trimming is suitable for sewing the light fabric like under-wear or irregular knitwear,
to improve the efficiency.
2. The design of the suction inlet of the trimmer makes the trimming faster.
3. For those special fabrics such as mesh fabric, mercerized cotton etc, the stitches are easily
accomplished as well as the trimming by the professional computer controlled without mistaketrimming.
4. Functions with auto stop sewing after trimming and with no fabric can save the stitches.
5. VTA trimmer is controlled by air cylinder, which reduces the blade stroke times and extends the
durability.

Front/middle sensorsFoot LifterPneumatic Set
Suction SetSuction Channel
CTEVPneumaticVV
CTE-UVPneumaticVV

Available Model: 747L 757L, 747LQ, 757LQ
Self-installation : Y

DKL①② / DKK①②

Direct-drive Servo Motor

Overlock machine equipped with the modularized direct-drive servo motors to be more flexible for diversification.
①=Manufacturer code ②=Version code + Function code

Available Model: All Overlock Series
Self-installation : Y

EC

Electric Type Tape / Elastic Trimmer

Cuts tape/ elastic by pressing the button.
1. EC-K: Standard knife (16 mm”) EC-K-A: Long knife (22 mm”)
2. Hand-control button : standard Knee-control paddle (FEC34-A) : Optional

Available Model: MODEL w/LFC-3, MDDEL w/PS, MODEL w/TG
Self-installation : Y

ECA

Pneumatic Type Tape / Thread Cutter ( With Auto / Manual Switch Function)


ECB

Solenoid Type Tape / Thread Cutter ( With Auto / Manual Switch Function )

Brand new sensor upgrades the performance. ECA is pneumatic type, and ECB is electric type,compatible with air suction slot, which makes the operation more smoothly.

  1.  Manual, semi-auto and fully-auto operation mode, attached the switch keys, and could be adjusted by the panel.
  2.  Mistake-proof protection device: One sensor equipped near the trimmer. If the sensor is blocked, the trimmer is deactivated effectively for avoiding from cutting the fabric.
  3. Manual trimming compensation stitch key: If the thread is not cut due to the operation, it can be done by the key.
  4.  Under the manual mode, it could be fully backward pedaled to cut the thread.
  5. For those special fabrics such as mesh fabric, mercerized cotton etc, the stitches are easily accomplished as well as the trimming by the professional computer controlled without mistaketrimming.
Three sensorsCutterFoot Lifter件Pneumatic Set
Suction SetSuction Channel
ECA / ECA-UVPneumaticPneumaticVV
ECB / ECB-UVElectricElectricVV

Available Model: 737L, 747L 757L, 767L, 737LQ,747LQ, 757LQ
Self-installation : Y

FG

Side Tape Holder

For tape feeding, on the right side of the table.

Available Model: MODEL w/PS, MODEL w/TA
Self-installation : Y

GA

Gathering Device

Continuous or intermittent random gathering on lower ply.
P: Piping folder KV57 (tape width 25mm / finish width 6mm) is optional. For piping with rope inside, presser foot requires a trench, which is marked with P at the end of parts code. eg
P204P.

Available Model: 747KT-514H, 747L-514M-8, 747L-516M-8
Self-installation : Y

GAS

Gathering Presser-foot

Continuous or intermittent random gathering on lower layer of fabric.
Part NO. ZGL04-P324-A

Available Model: 747L-514M
Self-installation : Y

GAL

Flounce/Falbala Fine Edging

Elastic fabric fine serging with a pull-back device makes flounce/ falbala style.Adjust the pressure of pull-back plate to have big or small waves.

Available Model: 737L-504F-2
Self-installation : Y

KB301

Simple Anti Curly Selvedge Device

Easy to install, effectively solve curly selvedge problem.

Available Model: MODEL 700L, MODEL 700LQ, MODEL 700KT
Self-installation : Y

KB561-A

Flat Bed Cloth Plate

To convert cylinder bed machine into flat bed machine. For normal overlock sewing
operation.

Available Model: 700KS
Self-installation : Y

FA

Side Electric Tape Feeding

1. With electronic switch to control the feeding length of tape, elastic, or lace to create
smoother sewing.
2. Tape feeding will be on the right hand side of the control box.

Available Model: 700L
Self-installation : Y

LFA

Electric Type Upper Tape Feeding Device

To keep constant tension for sewing. Elastic tape is fed by motor for zero tension and
required length.
Voltage, 110V(Part NO. LFA-1A) / 220V(Part NO. LFA-2A)

Available Model: MODEL w/LFC-3, MODEL w/TG
Self-installation : Y

LF290

Untangline Wheel

An optional device to be equipped with LFA (tape feeding device). Untangling the elastic tape by reverse rotation wheel is a pre-feeding process.
Voltage, 110V(Part NO. LF290-A1) / 220V(Part NO. LF290-A2)

Available Model: MODEL w/LFA
Self-installation : Y

LFC-3

Mechanical Type Elastic Feeding

To Control elastic tape tension by adjusting the gear.
Presser foot:
P216-3 for 3 thread
P216-4 for 4 thread
Standard is P216. Special demand by request.

Presser FootP216P217P218WP219
Elastic Size2-13mm2-20mm2-30mm2-35mm

Self-installation : Y

LS

Upper Tape Holder

For top feeding tape or elastic.

Available Model: MODEL w/LFC-3, MODEL w/TG
Self-installation : Y

PS

Pocket Sewing

Overlock sewing with tape binding for strengthening the pocket edge.
PS201: Folder, for tape size 3/8″ (9.5mm)

Available Model:757L-516M-3
Self-installation : Y

TA

Two Chain stitch Pocket Sewing Device

Tape binding by two chainstitch sewing for strengthening the pocket edge.
Standard folder(tape width 25.4mm/ finish width 6.4mm)

Available Model:757L-401M-8-30, 757L-401M-8-50
Self-installation : Y

TBK

Machine Body Supporter for Full Submerged Table

700K series Machine base for Full submerger table

Available Model:Table 700K-T2
Self-installation : Y

TG

Tape Guide

To prevent knit wear shoulder stretching, insert woven tape for strengthening.
P254J-4A: Presser foot for maximun tape width is 13 mm.

Available Model:747L-514M-3, 747L-514H-4
Self-installation : Y

High-end electronic control type
Mechanical type

UC

Top and Bottom Anti-Curly Edge

The pneumatic device solves the problem of curly edge material. The fabric edge is flattened
by air before entering the presser foot. Applicable to up-roll, down-roll, and all kinds of curly edge situations, which highly improves the sewing efficiency.
There are 3 types for this device. UC-LD (High-end electronic control type), UC-L2 (economic mechanical type), and UC-L3 (Up-roll only type).

Available Model:700L Series
Self-installation : Y

VT

Side Suction Thread Chain Cutter Device

Take thread into trimmer tube by suction motor or air compressor. (Applicable for 3~4 thread
machine)

Available Model:737L, 747L, 737KS, 747KS
Self-installation : Y

VTE VTE-U

Side Suction Auto Thread Chain Cutter Device (with Sensor-controlled Energysaving Device )

Our computerized system drives sensor-controlled energy saving device. Sensor checks the fabric edge. Turn the button of control box to set the time of air suction of chain-cutter. It saves the energy consuming of air compressor system and also saves thread consuming.

Front/middle sensorsFoot LifterPneumatic Set
Suction SetSuction Channel
VTEVPneumaticVV
VTE-UVPneumaticVV

Available Model:737L 747L, 737LQ, 747LQ
Self-installation : N

WR/LFC-3

Spaghetti Sewing

Overlock sewing at knit tape edge and then turn it into tube. For swimwears, night gowns etc.
Folder size: tape width is 22.2mm, finished tube size is 5mm in diameter

Available Model:737L, 747L
Self-installation : Y

TUA-3X

Spaghetti Sewing

CodeFunctional SectionApplicable SeriesRemark
Vacuuming WayPresser Foot LifterAir SwitchFilter
FrontBackTrimmerMechanical TypeSolenoid Type
TUA-31-Double ways--700K / L / KS / KST / KTThe treadle rod of 700K/ Q is shared.
TUA-31-A-Double ways-700K / L / KS / KST / KTThe treadle rod of 700K/ Q is shared.
TUA-32KDouble ways--700K / L / KS / KST / KT / LQFor 700LQ SIMPLE TYPE
TUA-33K--Single way700KHD-40-2-7K
TUA-34K-Double ways700KHD-40-2-7K
TUA-32KTDouble ways--700KT-
TUA-34KT-Double ways700KTHD-40-2-7K
TUA-36No retail, exclusive CTE, ECA, ECB, VTE ,VTA for 700LD(Allocated with the sensor, power-and-wind-saved device)
TUA-37S---Single way700KS / KSTGD-40-4-7K-220
TUA-38S--Double ways700KS / KSTGD-40-4-7K-220
*only for 700KS
TUA-39S--Single way--700KS / KST
TUA-40S-Double ways--700KS / KST*only for 700KS
TUA-38ST--Double ways700KSTGD-40-4-7K-220
*only for 700KST
TUA-40ST-Double ways--700KST*only for 700KST
TUA-41S--Double ways700KS / ESKi60-4-ES
*only applicable to 700KS/ESK
adapter spec
TUA-41ST--Trigeminy700KS / RSKi60S-4-RS
*only for 700KST
*with sensor-controlled flick
function for cross seam
mechanism
TUC-01-Trigeminy700K /LFor ECA-U
TUC-02---Single way700K /LFor ECB-U
TUC-03--Trigeminy700K /LFor VTE-U
TUC-04--Double ways700K /LFOR CTE-U
TUC-05--Double ways700LFOR VT
TUC-05-A--Double ways700L*cylinder group with presser
foot EC413U-A
TUC-07-Trigeminy700LQFor ECA-U??VTE-U
TUC-08-Trigeminy700LQFor VTE-Q
TUC-09---Single way700LNo presser foot lifter, only front
and back vacuuming

*TUA-37S、TUA38S、TUA39S、TUA40S、TUA-38ST、TUA40ST、TUA41S、TUA41ST  Open type table required.

*Remark: The solenoid must be driven by full function servo motor. The adapter spec is 15-Pin (Hohsing iseries).
   TSA Series andSimple type direct-drive servo motor are not applicable.
